    8mm | 24V | 14.2cut | 490LED |Ultra Density | 3850

    Strong pure copper LED frame, and diameter>1mm, 99.9%-purity gold wire encapsulation, can reduce the LED damage in different applications.

    Request A Quote
    Category:

    Technical Details

    Part No.

    DL-F21A245V24-3850-*

    SMD Type

    2110 Series

    LED Qty

    490 LEDs/m

    Voltage

    DC 24V

    Power Option

    18W/m

    Lumen/m (max.)

    1580

    Lumen/W (max.)

    110

    Color

    White

    CRI

    Ra ≥90 , Ra ≥95

    PCB Width

    8mm

    SDCM

    ≤5 Step 1Bin

    Related Specifications

    Length: 5M(16.4′)/roll

    Cutting Unit: 7LEDs/14.28mm(0.562′′)

    LED Spacing: 2.04mm(0.080′′)

    LED Height: 1.2mm(0.047′′)

    Mounting: 3M tape

    Min. Bend Diameter: Φ60mm(2.362′′)

    Copper foil: 2oz

    Product Photo-electric Parameters

    Power CRI Color Color Temperature LM/m LM/W Energy Efficiency Class
    14.4W Ra≥95 WW 2700K 1350 94 F
    14.4W Ra≥95 WW 3000K 1395 97 F
    14.4W Ra≥95 NW 4000K 1450 101 F
    14.4W Ra≥95 NW 5000K 1510 105 F
    14.4W Ra≥95 PW 6500K 1580 110 E
