5mm | 12V | 120LEDs | 6W | 25cut | #2-5288 Ultra-Narrow LED Strip Light
Ultra-thin (3/4/5mm wide) strip light that is outfitted with extremely bright LED chips and a strong adhesive backing.Widely use in small & thin aluminum profile or the small gap lighting.
Technical Details
| Part No. |
DL-F20A60V12-2-5288-* |
|---|---|
| SMD Type |
2216 SMD |
| LED Qty |
120 LEDs/m |
| Voltage |
DC 12V |
| Power Option |
6W/m |
| Lumen/m (max.) |
840 lm//m @6500K |
| Lumen/W (max.) |
135 lm/W @6500K |
| Color |
White |
| CRI |
Ra ≥90 |
| SDCM |
≤5 Step 1Bin |
| PCB Width |
5mm |
| Beam Angle |
120° |
| IP Process |
IP20 ,IP67 ,IP68 |
| Warranty |
3 years |
Related Specifications
Length(max.): 5M(16.4′)/roll
Cutting Unit: 3LEDs/25mm(0.984′′)
LED Spacing: 8.3mm(0.326′′)
LED Height: 0.7mm(0.027′′)
Mounting: 3M tape
Min. Bend: Φ60mm(2.362′′)
Copper foil: 2oz
On-off times: 10000（test times）
Certification:UL
Certified:CE/RoHS
EMC compliance:EN 55015
Product Photo-electric Parameters
| Power | CRI | Color | Color Temperature | LM/m | LM/W | Energy Efficiency Class |
| 6W | Ra≥90 | WW | 2700K | 740 | 118 | E |
| 6W | Ra≥90 | WW | 3000K | 755 | 121 | E |
| 6W | Ra≥90 | NW | 4000K | 780 | 125 | E |
| 6W | Ra≥90 | NW | 5000K | 810 | 130 | E |
| 6W | Ra≥90 | PW | 6500K | 840 | 135 | D |
