10mm | 24V | 14.4W | 25cut | 11236-IP67 | SOB Single-Color LED Strip Light
- High brightness and uniform light.
- Compact Design & cut-free.
- Energy Efficiency.
- Multiple Color Temperature Options:1800k~6500k
- IP67 waterproof and Dustproof desgin.
- Highly flexible installation, outdoor use.
Technical Details
| Part No. |
DL-FSOBJ160V24-11236-IP67-* |
|---|---|
| SMD Type |
SOB |
| Voltage |
DC 24V |
| Power Option |
14.4W/m |
| Lumen/m (max.) |
1613 lm/m @4000K |
| Lumen/W (max.) |
112 lm/W @4000K |
| Color |
White |
| CRI |
Ra ≥90 |
| PCB Width |
8mm |
| Beam Angle |
120° |
| IP Process |
IP67 |
| Warranty |
3 years |
Related Specifications
length(max.): 5m(16.4′)
Cutting unit: 8LEDs/25mm(0.98″)
LED Spacing: 3.125mm(0.15″)
Width: 10mm
Height: 6.5mm
Mounting: 3M tape
Min. bend: Φ60mm(2.36″)
Copper foil: 2oz
On-off times: 10000
Certification: UL
Certified: CE/RoHS
EMC compliance: EN 55015
Product Photo-electric Parameters
| Power | CRI | Color | Color Temperature | LM/m | LM/W | Energy Efficiency Class |
| 14.4W | Ra≥90 | SWW | 2700K | 1469 | 102 | F |
| 14.4W | Ra≥90 | WW | 3000K | 1555 | 108 | F |
| 14.4W | Ra≥90 | NW | 4000K | 1613 | 112 | E |
| 14.4W | Ra≥90 | PW | 6500K | 1555 | 108 | F |
Product Downloads
Specification
Testing Report
Certificate
Product Accessories
No accessories for this product now！
