10mm | 24V | 33.3cut | 16W | 14207 | SOB Dim to Warm LED strip light
- The SOB Dim to Warm LED Strip Light offers natural, seamless dimming for perfect lighting. As you dim the lights, the color temperature automatically shifts from 3000K to 1800K, creating a warmer ambiance.
- The flexible SOB Dim to Warm LED Strip Light is easily dimmable and controllable with TRIAC, PWM dimming, and 0/1-10V dimming.
- Advanced LED technology enables this dynamic strip to produce a candle-like glow similar to traditional incandescent lighting, while offering innovative versatility and peak performance, suitable for almost any space.
- No need for extra covers, making it perfect for areas with low clearance or reflective surfaces to eliminate spot-glare. Applications include general accent lighting, shelving lighting, cove lighting, lobby lighting, commercial lighting, backlighting, and more.
Categories: SOB Series, Dim To Warm Series
Technical Details
Part No. |
DL-FSOBA210V24-14207-* |
---|---|
SMD Type |
SOB |
Voltage |
DC 24V |
Power Option |
16W/m |
Lumen/m (max.) |
1352 lm/m @3019K |
Lumen/W (max.) |
82 lm/W @3019K |
Color |
CCT |
CRI |
Ra โฅ90 |
Beam Angle |
120ยฐ |
IP Process |
IP20 ,IP66 |
Warranty |
5 years |
Related Specifications
length(max.):ย 5m(16.4โฒ)
Cutting unit: 14LEDs/33.33mm(1.31โณ)
LED Spacing: 2.381mm(0.09โฒโฒ)
LED Height: 2.6mm(0.10โฒโฒ)
Mounting:ย 3M tape
Min. bend:ย ฮฆ60mm(2.36โณ)
Copper foil:ย 3oz
On-off times:ย 10000๏ผtest times๏ผ
Certification: UL
Certified: CE/RoHS
EMC compliance: EN 55015
Product Photo-electric Parameters
Raโฅ90 | |||||
Dimming ratio | Power | CCT | LM/m | LM/W | Energy Efficiency Class |
10% | 1.3W | 1953K | 46 | 35 | G |
20% | 2W | 1988K | 97 | 48 | G |
30% | 2.7W | 2048K | 149 | 55 | G |
40% | 3.6W | 2161K | 223 | 61 | G |
50% | 4.9W | 2334K | 325 | 66 | G |
60% | 6.8W | 2542K | 470 | 69 | G |
70% | 9.2W | 2713K | 650 | 70 | G |
80% | 11.7W | 2844K | 863 | 74 | G |
90% | 13.4W | 2939K | 1078 | 80 | G |
100% | 16.4W | 3019K | 1352 | 82 | G |
Product Downloads
Specification
Testing Report
Certificate
Product Accessories
No accessories for this product now๏ผ
