10mm | 24V | 224LEDs | 24W | 62.5mm/cut | #18200 | Mixes RGB+W Color LED Strip
- Mixes 2835RGB + 2216White LEDs to deliver both dynamic RGB effects and tunable white lighting.
- Lighting modes can seamlessly switch between vibrant RGB colors and adjustable white tones via compatible LED controllers.
- Consistent color mixing ensures uniform visual output and enhanced lighting performance.
- High-quality PCB ensures reliable performance and compatibility with standard LED profiles.
- Ideal for dynamic lighting applications in residential, hospitality, and retail environments.
Technical Details
| Part No. |
DL-F28+22A112V24-18200-* |
|---|---|
| SMD Type |
2216 SMD ,2835 SMD |
| LED Qty |
224 LEDs/m |
| Voltage |
DC 24V |
| Power Option |
24W/m |
| Lumen/m (max.) |
1446 lm/m @RGBW |
| Lumen/W (max.) |
61 lm/W @RGBW |
| Color |
RGBW |
| CRI |
Ra ≥90 ,Ra ≥95 |
| PCB Width |
10mm |
| Beam Angle |
120° |
| IP Process |
IP20 ,IP66 ,IP54 ,IP65 ,IP67 ,IP68 |
| Warranty |
3 years |
Related Specifications
Length(max.): 5M(16.4′)/roll
Cutting Unit: 14LEDs/62.5m(2.46′′)
LED Height: 1.45mm(0.06′′)
Mounting: 3M tape
Min. Bend: Φ60mm(2.36′′)
Copper foil: 3oz
Lifetimes: 5000h
Eye security:IEC 62471
Certified:CE/RoHS
EMC compliance:EN 55015
Product Photo-electric Parameters
| Power | Color | Wavelength(λ) | LM/m | LM/W | Erp |
| 24W/m | RGBW | / | 1446 | 61 | G |
| 14W/m | RGB | / | 608 | 43 | G |
| 7W/m | Red | 620~625nm | 144 | 21 | G |
| 4.6W/m | Green | 520~525nm | 399 | 88 | F |
| 4W/m | Blue | 460~465nm | 74 | 19 | G |
| 10W/m | White( 2700k /Ra95 ) | / | 850 | 85 | F |
