16*16mm | 24V | 24LEDs | 21W | 125mm/cut | #16693 | 1616 RGB Side-Bendable Wall Washer LED
- Provides vibrant RGB lighting effects, suitable for various decorative needs.
- Side and top bendable design allows flexible installation on complex surfaces.
- Lensed design ensures uniform light distribution and effective wall-washing.
- Stable power input with high power output of 21W per meter for optimal brightness and efficiency.
- Maximum production length of 2000mm reduces connection frequency, improving installation efficiency.
- Applications: Ideal for parks, commercial spaces, stage lighting, exhibitions, and indoor decoration.
Technical Details
| Part No. |
DL-F30C12V24-16693-* |
|---|---|
| SMD Type |
3030 SMD |
| LED Qty |
24 LEDs/m |
| Voltage |
DC 24V |
| Power Option |
21W/m |
| Lumen/m (max.) |
986 lm/m @RGB |
| Lumen/W (max.) |
48 lm/W @RGB |
| Color |
RGB |
| PCB Width |
12mm |
| Beam Angle |
40° ,50° |
| IP Process |
IP67 |
Related Specifications
Connection Length: 5M(16.4′)
Cutting Unit:6LEDs/125mm(4.921″)
LED Spacing: 20.833mm(0.82″)
LED Height: 9.0mm(0.354″)
Min. Cutting Unit: 6 LEDs
Min. Cutting Length: 125mm
Copper foil: 2oz
Lifetime: 50000h
IP Process: IP67
Warranty: 3 years
Product Photo-electric Parameters
| Power | Color | Wavelength(位) | LM/m | LM/W | Erp |
| 21W/m | RGB | / | 986 | 48 | G |
| 7.4W/m | Red | 630~635nm | 233 | 32 | G |
| 7.7W/m | Green | 515~520nm | 660 | 85 | F |
| 5.6W/m | Blue | 465~470nm | 141 | 25 | G |
Product Downloads
Specification
Testing Report
Certificate
Product Accessories
No accessories for this product now！
