10mm | 24V | 128LEDs | 9.6W | 62.5cut | #10120 | 2835 High Light Efficacy High Lumen LED Strip

Name: 10mm | 24V | 128LEDs | 9.6W | 62.5cut | #10120 | 2835 High Light Efficacy High Lumen LED Strip - Shenzhen Deno Lighting Electronic Co., Ltd
SKU: DL-F28A64V24-10120-*

Deno Lighting focuses on high efficiency LED strips and therefore complies with the European ErP EcoDesign regulation. With the high efficiency LED strips series the demands of the legislator are met, ensuring environmentally friendly LED lighting strips.

Up to 205lm/Wfor a high degree ofefficiency.

8 led/per cutting unit;

128led/m to ensure continuous lightwithout dots;

5m length no brightness dropped to keep high light efficiency at the same time.

Category: High Light Efficacy Series

Technical Details

Part No.	DL-F28A64V24-10120-*
SMD Type	2835 SMD
LED Qty	128 LEDs/m
Voltage	DC 24V
Power Option	9.6W/m
Lumen/m (max.)	1925 lm/m @4000K
Lumen/W (max.)	219 lm/W @4000K
Color	White
CRI	Ra ≥80 , Ra ≥90 , Ra ≥95
SDCM	≤3 Step 1Bin
PCB Width	10mm
Beam Angle	120°
IP Process	IP20 , IP66 , IP65
Warranty	5 years

Related Specifications

Length(max.): 10M(32.8′)/roll

Cutting Unit: 8LEDs/62.5mm(2.460′′)

LED Spacing: 7.8mm(0.307′′)

LED Height: 2.1mm(0.082′′)

Mounting: 3M tape

Min. Bend: Φ60mm(2.362′′)

Copper foil: 3oz

Pure Gold wire: 99.99%

On-off times: 10000（test times）

Eye security:IEC 62471

Certification:UL

Certified:CE/RoHS/ETL

EMC compliance:EN 55015

Product Photo-electric Parameters

CRI≥80

Power	CRI	Color	Color Temperature	LM/m	LM/W	Energy Efficiency Class
9.6W	Ra≥80	SWW	1900K	1460	166	C
9.6W	Ra≥80	SWW	2300K	1625	185	B
9.6W	Ra≥80	WW	2700K	1750	200	B
9.6W	Ra≥80	WW	3000K	1840	210	A
9.6W	Ra≥80	WW	3500K	1870	213	A
9.6W	Ra≥80	NW	4000K	1925	219	A
9.6W	Ra≥80	NW	5000K	1920	219	A
9.6W	Ra≥80	PW	6500K	1840	210	A

CRI≥90

Power	CRI	Color	Color Temperature	LM/m	LM/W	Energy Efficiency Class
9.6W	Ra≥90	SWW	1900K	1345	153	D
9.6W	Ra≥90	SWW	2300K	1500	171	C
9.6W	Ra≥90	WW	2700K	1615	184	C
9.6W	Ra≥90	WW	3000K	1700	194	B
9.6W	Ra≥90	WW	3500K	1725	197	B
9.6W	Ra≥90	NW	4000K	1775	202	B
9.6W	Ra≥90	NW	5000K	1775	202	B
9.6W	Ra≥90	PW	6500K	1700	194	B

CRI≥95

Power	CRI	Color	Color Temperature	LM/m	LM/W	Energy Efficiency Class
9.6W	Ra≥95	WW	2700K	1310	149	D
9.6W	Ra≥95	WW	3000K	1385	157	D
9.6W	Ra≥95	WW	3500K	1420	162	C
9.6W	Ra≥95	NW	4000K	1465	167	C
